For BMW E70 Android Screen Replacement Apple CarPlay Multimedia Player
It is specially made for BMW X5/X5M E70/X6/X6M E71 (2007-2010) CCC system with 10pin LVDS.
BMW X5 E70 (2011-2013)/ BMW X6 E71 (2011-2014) CIC system with 4pin LVDS
10.25inch screen fit both RHD and LHD BMW E70 E71, 12.3inch screen fit only LHD BMW E70 E71.
Support split screen and PIP: Multi-tasking run 2 apps at the same time, picture in picture.
Keep original BMW X5 X6 system features such as factory radio, GPS navigation, Bluetooth, DVD/CD,USB,SD, etc,
support factory rear view camera reverse trajectory. 360 camera, door open warning, be compatible with original iDrive knob control
and steering wheel control, be compatible with original sound system and optic fiber, play lossless audio.
Android system functions include Android navigation, touch screen, android music and video, android Bluetooth call and Bluetooth music, USB port, SD card, android apps installation.
Built in GPS with rapid positioning and navigation support maps both online and offline.
Multi menu languages for choice：English, China, German, Spanish , Korean, Italian, Dutch, Russian, French, Portuguese, Japanese, Hebrew, Thai, Greek
Antiglare blueray screen optional.
|
Specification 1 (Real Android13) |
||
|
1 |
CPU |
Qualcomm Snapdragon 665(SM6125) Octa core 11nm LPP |
|
4 * A73 (2.0Ghz) + 4 * A53 (1.8Ghz) |
||
|
2 |
GPU |
Adreno 610 (950Mhz) |
|
3 |
OS |
Android 13 |
|
4 |
RAM ROM |
4+64GB/ 8+128GB/ 8+256GB EMCP chip eMMC5.1/UFS2.1+LPDDR4X |
|
5 |
Screen&Resolution |
10.25inch IPS LCD G+G Touch Screen 1280*480 /1920*720 |
|
12.3inch IPS G+G Touch HD Screen 1920*720 |
||
|
6 |
Bluetooth |
Bluetooth 5.0+ BR/EDR+BLE. |
|
7 |
WiFi |
IEEE 802.11 2.4G b/g/n 5G a/g/n/ac. |
|
8 |
4G SIM |
LTE Category 4：4DL Down 150Mbps 5UL Up 75Mbps |
|
9 |
Video |
Support 4K HD video, H.264 (AVC)，H.265 (HEVC) |
|
10 |
Image |
OpenGL ES 3.1+,OpenCL2.0 |
|
11 |
Carplay |
Wireless & Wired Apply Carplay, Wireless & Wired Android Auto, Support Phone Link |
|
Wireless and Wired Phone Mirroring |
||
|
12 |
Camera |
AHD CCD Reverse Camera |
|
13 |
GPS |
GPS/Beidou/Glonass,support built in or on-line maps |
|
14 |
Extend Memory |
Support Micro TF card slot, USB port. 128M max |
|
15 |
Suppot |
Real Time Weather ;Ota (on-line upgrade) |
|
16 |
Optional |
360 Panoramic View Camera optional |
|
|
|
|
|
Specification 2 (Android13) |
||
|
1 |
CPU |
Qualcomm snapdragon 680 (SM6225) Octa core 6nm LPP |
|
Octa core Kryo Gold (2.4Ghz)+Kryo Silver (1.9Ghz) |
||
|
2 |
GPU |
Adreno 610 (950Mhz) |
|
3 |
OS |
Android 13 |
|
4 |
RAM ROM |
6+64GB/ 8+128GB/ 8+256GB |
|
5 |
Screen&Resolution |
10.25inch IPS LCD G+G Touch Screen 1280*480 /1920*720 . |
|
12.3inch IPS G+G Touch HD Screen 1920*720 |
||
|
6 |
Bluetooth |
5.1 + BR/EDR+BLE. |
|
7 |
WiFi |
IEEE 802.11 2.4G . |
|
8 |
4G SIM |
LTE Category 4：4DL Down 150Mbps 5UL Up 75Mbps for Asia Europe |
|
9 |
Video |
Support 4K HD video, H.264 (AVC)，H.265 (HEVC) |
|
10 |
Image |
support OpenGL ES 3.1+,OpenCL2.0 |
|
11 |
Carplay |
Wireless Carplay, Wired Android Auto through USB |
|
12 |
Camera |
AHD CCD Reverse Camera |
|
13 |
GPS |
GPS/Beidou/Glonass,support built in or on-line maps |
|
14 |
Extend Memory |
Support Micro TF card slot, USB port. 128G max |
