Audi Q5 Android Screen Display Upgrade Apple Carplay

Ugode Android10 /Android13 Touch Screen Replacement Upgrade Retrofit for Audi Q5

Short Description:

Ugode Android Screen Display Special for Audi Q5

Audi Low version LHD (left hand drive) | RHD (right hand drive): Q5 (2009-2016)

Audi High version LHD (left hand drive)| RHD (right hand drive): Q5 (2009-2016)

* High level & Low level supported, but they are different models. need to distinguish

*  Keep original radio features after upgrade, such as radio , CD , GPS navigation, bluetooth, Joystick knob control, etc.

*  Car Dashboard information display.

*  Multiple functions and big screen enhance car performance.

* 4G LTE or Wifi network

* Bluetooth handfree call and music play

* On line and off line GPS Navigation

* HD Video playing

* Split screen function for gps map and video at same time

* Personal UI interface set in different colors and style

*  Android 10:

  Wireless Carplay

  Wired Android Auto through USB

*  Android 13:

  Wireless & Wired Apply Carplay

  Wireless & Wired Android Auto, Support Phone Link


Features

Specification

Video

Product Tags

It is specially made for Audi Q5 without or without AMI 2009-2016 year.

10.25inch or 12.3inch screen fit both LHD and RHD Audi Q5.  but frame stand is different position.

Audi Q5 has low profile and high profile difference. need to check the dashboard before order.



1, Full lamination G+G Capacitance touchscreen (1920 x720 resolution).

2, Retain original radio features.

3, Double System Conversion, Original Audi AMI system &Android System. Support switching from android system to display original screen and functions.

4, You don't need to buy any carplay dongle anymore.

5, Support split screen: Multitasking run 2 apps at the same time share the screen with your family while you drive with navigation.

6, Original Audi AMI system: Support all the original Audi mmi functions, like factory radio, GPS navigation, Bluetooth, DVD/CD, USB, SD, etc, support factory rear view camera reverse trajectory. 360 camera, door open warning, be compatible with original joystick, touch mouse and steering wheel control, be compatible with original sound system and optic fiber, play lossless audio.

7, Android system functions include Android navigation, touch screen, android music and video, android Bluetooth call and Bluetooth music, USB port, SD card, android apps installation.

8, Built-in A2DP, Hands-free calling, Transfer phonebook with alphabetic name search, Caller record, Call history.

9, Support common video formats: MP4, AVI, MKV, WMV, MOV, FLV and other common video formats.

10, Support common audio formats: MP3, WMA, AAC, FLAC, APE, WAV and other common audio formats.

11, GPS rapid positioning and navigation, support google map and waze etc.

12, Support original OEM rear camera and aftermarket rear camera (there is selection in setting for camera type).

13, Built in GPS, Support Waze, google on-line maps, etc.

14, Internal wifi and 4G LTE (4G LTE support European and asian countries only).

15, Multi languages for choice: English,China, German, Spanish, Korean, Italian, Dutch, Russian, French, Portuguese, Japanese, Hebrew, Thai, Greek.

16, Three Audi AMI style UI inside settings for choice.

17, Car information display.

18, Support steering wheel control and Mouse knob control.

19, Support 3 major satellite systems: GPS / Beidou / Glonass, high sensitivity!

20, Automatic support for AUX Switch - Some old cars are manually switched.

21, Android10: Wireless Apple Carplay, Wired Android auto.

22, Android11: Wireless/Wired Apple Carplay, Wireless/Wired Android auto, support phone link.



详情


  • Previous:
  • Next:

  • Specification 1 (Real Android13)

    1

    CPU

    Qualcomm Snapdragon 665(SM6125) Octa core 11nm LPP

     4 * A73 (2.0Ghz) + 4 * A53 (1.8Ghz)

    2

    GPU

    Adreno 610 (950Mhz)

    3

    OS

    Android 13

    4

    RAM ROM

    4+64GB/ 8+128GB/ 8+256GB EMCP chip eMMC5.1/UFS2.1+LPDDR4X

    5

    Screen&Resolution

    10.25inch IPS LCD G+G Touch Screen  1280*480 /1920*720

    12.3inch IPS G+G Touch HD Screen 1920*720

    6

    Bluetooth

    Bluetooth 5.0+ BR/EDR+BLE.

    7

    WiFi

    IEEE 802.11 2.4G b/g/n 5G a/g/n/ac.

    8

    4G SIM

     LTE Category 44DL Down 150Mbps 5UL Up 75Mbps

    9

    Video

    Support 4K HD video, H.264 (AVC)H.265 (HEVC)

    10


    OpenGL ES 3.1+,OpenCL2.0

    11

    Carplay

    Wireless & Wired Apply Carplay, Wireless & Wired Android Auto, Support Phone Link

    Wireless and Wired  Phone Mirroring

    12

    Camera

    AHD CCD Reverse Camera

    13

    GPS

    GPS/Beidou/Glonass,support built in or on-line maps

    14

    Extend Memory

    Support Micro TF card slot, USB port. 128M max

    15

    Suppot

    Real Time Weather ;Ota (on-line upgrade)

    16

    Optional

    360 Panoramic View Camera optional







    Specification 2  (Android13)

    1

    CPU

    Qualcomm snapdragon 680 (SM6225) Octa core 6nm LPP

    Octa core Kryo Gold  (2.4Ghz)+Kryo Silver (1.9Ghz)

    2

    GPU

    Adreno 610 (950Mhz)

    3

    OS

    Android 13

    4

    RAM ROM

     6+64GB/ 8+128GB/ 8+256GB

    5

    Screen&Resolution

    10.25inch IPS LCD G+G Touch Screen 1280*480 /1920*720 .

    12.3inch IPS G+G Touch HD Screen 1920*720

    6

    Bluetooth

    5.1 + BR/EDR+BLE.

    7

    WiFi

    IEEE 802.11 2.4G .

    8

    4G SIM

    LTE Category 44DL Down 150Mbps 5UL Up 75Mbps for Asia Europe

    9

    Video

     Support 4K HD video, H.264 (AVC)H.265 (HEVC)

    10


    support OpenGL ES 3.1+,OpenCL2.0

    11

    Carplay

    Wireless Carplay, Wired Android Auto through USB

    12

    Camera

    AHD CCD Reverse Camera

    13

    GPS

    GPS/Beidou/Glonass,support built in or on-line maps

    14

    Extend Memory

    Support Micro TF card slot, USB port. 128G max
