AUDI A6 2005-2011 Original Style Android Display Autoradio CarPlay
It is specially made for Audi A6 2005-2011 year.
It is original style, screen built in frame, screen with frame.
Audi A6 2005-2009 usually without AUX or AMI for sound, need add optic fiber most box.
Audi A6 2010-2011 usually with AUX or AMI for sound
8.8inch screen fit both LHD and RHD Audi A6. but they are with different frame bracket.
Support split screen and PIP: Multi-tasking run 2 apps at the same time, picture in picture.
Keep original AMI radio system features such as factory radio, GPS navigation, Bluetooth, DVD/CD,USB,SD, etc,
support factory rear view camera reverse trajectory. 360 camera, door open warning, be compatible with original iDrive knob control
and steering wheel control, be compatible with original sound system and optic fiber, play lossless audio.
Android system functions include Android navigation, touch screen, android music and video, android Bluetooth call and Bluetooth music, USB port, SD card, android apps installation.
Built-in A2DP, Hands-free calling,Transfer phonebook with alphabetic name search, Caller record, Call history.
Support common video and audio formats: MP4, AVI, MKV, WMV, MOV, FLV and MP3, WMA, AAC, FLAC, APE, WAV other common formats.
Built in GPS with rapid positioning and navigation support google map and waze etc.
Q: How to check if Audi auto radio is Low profile or high profile ?
A: The android screen hardware for AUDI low and high profile is different.
Please check the radio panel and dashboard for checking low or high system, the aircondition control of low profile is the radio panel. high version has knob control near gear.
|
Specification 1 (Real Android13) |
||
|
1 |
CPU |
Qualcomm Snapdragon 665(SM6125) Octa core 11nm LPP |
|
4 * A73 (2.0Ghz) + 4 * A53 (1.8Ghz) |
||
|
2 |
GPU |
Adreno 610 (950Mhz) |
|
3 |
OS |
Android 13 |
|
4 |
RAM ROM |
4+64GB/ 8+128GB/ 8+256GB EMCP chip eMMC5.1/UFS2.1+LPDDR4X |
|
5 |
Screen&Resolution |
10.25inch IPS LCD G+G Touch Screen 1280*480 /1920*720 |
|
12.3inch IPS G+G Touch HD Screen 1920*720 |
||
|
6 |
Bluetooth |
Bluetooth 5.0+ BR/EDR+BLE. |
|
7 |
WiFi |
IEEE 802.11 2.4G b/g/n 5G a/g/n/ac. |
|
8 |
4G SIM |
LTE Category 4：4DL Down 150Mbps 5UL Up 75Mbps |
|
9 |
Video |
Support 4K HD video, H.264 (AVC)，H.265 (HEVC) |
|
10 |
Image |
OpenGL ES 3.1+,OpenCL2.0 |
|
11 |
Carplay |
Wireless & Wired Apply Carplay, Wireless & Wired Android Auto, Support Phone Link |
|
Wireless and Wired Phone Mirroring |
||
|
12 |
Camera |
AHD CCD Reverse Camera |
|
13 |
GPS |
GPS/Beidou/Glonass,support built in or on-line maps |
|
14 |
Extend Memory |
Support Micro TF card slot, USB port. 128M max |
|
15 |
Suppot |
Real Time Weather ;Ota (on-line upgrade) |
|
16 |
Optional |
360 Panoramic View Camera optional |
|
|
|
|
|
Specification 2 (Android13) |
||
|
1 |
CPU |
Qualcomm snapdragon 680 (SM6225) Octa core 6nm LPP |
|
Octa core Kryo Gold (2.4Ghz)+Kryo Silver (1.9Ghz) |
||
|
2 |
GPU |
Adreno 610 (950Mhz) |
|
3 |
OS |
Android 13 |
|
4 |
RAM ROM |
6+64GB/ 8+128GB/ 8+256GB |
|
5 |
Screen&Resolution |
10.25inch IPS LCD G+G Touch Screen 1280*480 /1920*720 . |
|
12.3inch IPS G+G Touch HD Screen 1920*720 |
||
|
6 |
Bluetooth |
5.1 + BR/EDR+BLE. |
|
7 |
WiFi |
IEEE 802.11 2.4G . |
|
8 |
4G SIM |
LTE Category 4：4DL Down 150Mbps 5UL Up 75Mbps for Asia Europe |
|
9 |
Video |
Support 4K HD video, H.264 (AVC)，H.265 (HEVC) |
|
10 |
Image |
support OpenGL ES 3.1+,OpenCL2.0 |
|
11 |
Carplay |
Wireless Carplay, Wired Android Auto through USB |
|
12 |
Camera |
AHD CCD Reverse Camera |
|
13 |
GPS |
GPS/Beidou/Glonass,support built in or on-line maps |
|
14 |
Extend Memory |
Support Micro TF card slot, USB port. 128G max |
