Platform (U9 series-Car DVD Player)


1. High definition 16:9LCD display (1024x600 resolution),Standard lPS Capacitive touch screen.
2. Car gauge radio tuner, FM/AM RDS,54 preset station.
3. Bulit-in Bluetooth v4.0 with A2DP, Hands-free, Transfer phonebook with alphabetic name search, Caller record, Call history.
4. Support 1080P video player, MPEG2, MPEG4, H.264, VC-1, RM, RMVB, AVS, VP6, VP8, MKV. AI, MP4, MOV, WMV, etc.
5. GPS rapid positioning and navigation, support google map and waze etc.
6. Fakra GPs antenna.
7. Support 720P HD DVR, record and save the image data into SD card.
8. 4*45W power amplifier.
9. Support Front camera, 1TB HD and OBD.
10. Support Waze, google on-line maps, etc.
11. Internal wifi builitin with external wifi antenna.
12. Mirror link two way control.
13. Build in DAB+ Digital radio option; Build in Digital TV optional; Build in CarplaylAndroidAuto optional.
14. ST7850/7851, 10000uF capacitor, high-fi sound.


1. CPU ARM Cortex A9 Quadcore/Octa core, main frequency1.6GHz/2GHz
2. MCU ST 8S207
3. Ram 1G/2G MHz Sumsung DDR3
4. Rom 16GB/32GB Sumsung Flash
5. GPU Mali-400 3D graphic engine/SGX544MP1
6. Hannstar HD LCD 1024*600
7. Car standard capacitive touchscreen
8. Radio tuner NXP6686
9. Bluetooth CSR
10. Amplifier IC ST TDA7388(ST7850)
11. Audio IC ST 7729
